waste paper baling machine

waste paper baling machine –

are built for making bale of 10kgs to 60kgs.equipped with upto 3 cylinder, horizontal machine is available in different variant viz. manual, semi automatic, fully automatic hydraulic waste paper baling press machine.suitable for pressing waste paper,paper,carton etc.
carton press machine for pressing scrap generated from human resources day to day in daily life .so we introduced this machine for pressing carton scrap

waste paper baling press machine –

  • waste paper baling machine Medium Category machine equipped with three cylinders.
  • Efficient for producing bales of medium weight ranging from 75Kg to 155Kg
  • Average Baling time is 60-70 seconds.
  • Machine is available in different sizes meant for satisfying needs of all kind.

waste paper baling press machine pressing paper scrap and paper waste to avoid the over usage of scrap over area,godown or any place,baling machine presses scrap

  • waste paper baling machine – Medium Category machine equipped with three cylinders.
  • Efficient for producing bales of medium weight ranging from 25Kg to 50Kg in waste paper.
  • Average Baling time is 60 seconds.
  • Machine is available in different sizes meant for satisfying needs of all kind.

waste paper baling machine

waste paper baling machine-

IN DOUBLE ACTION MODEL– NEED ROPE TO TIE A BALE FOR PAPER,CARDBOARD,CARTON,CORRUGATED BOXES,WASTE PAPER

We are expert in fabricating Hydraulic Mini Baler with high grade of raw material using sophisticated machinery. Our cylinders are widely appreciated for robust structure, corrosion resistant and high performance

Sl. No. Specification Sh-001 Sh-002 Sh-003 Sh-004
1 Container Box Size (inch) 20″x18″x56″ 22″x20″x56″ 22″x22″x57″ 24″x22″x57″
2 Pressed Bale Size (inch) 12″ x 18″ 12″ x 20″ 13″ x 22″ 13″ x 24″
3 Pressed BaleWeight (Kg)approx. 15-25(in ms scrap)10-18(in carton)10-20(in aluminium)10-20(pet bottle) 20-40(in ms scrap)15-25(in carton)15-25(in aluminium)15-25(pet bottle) 35-60(in ms scrap)20-35(in carton)20-25(in aluminium)20-35(pet bottle) 45-70(in ms scrap)30-50(in carton)20-35(in aluminium)30-50(pet bottle)
4 Electric Motor (HP) 20 20 25 25
5 Pressing Scrap Time (second) 35-40 40-45 45-50 50-55
6 Production/Shift (tons) 6-8 8-10 10-12 12-14
7 Oil Tank Capacity (Ltr.) 700 700 700 700


NO NEED OF ROPE TO TIE A BALE 100% IN waste paper baling machine TRIPLE ACTION MODEL(why to waste million of wire rope to tie a bale)

Triple Action Mini Jumbo- (scrap press from 3 sides)waste paper baling press

Any situation where there is a need for a baler or compactor that is small, easy to operate, produces very small bales that are light weight and easy to handle. Basically these are machines that have refrigerator style doors with push button type controls that have a mix of features found on both balers and compactors.

Sl. No. Specification Sh-783 Sh-784 Sh-785 Sh-786
1 Container Box Size (inch) 20″x20″x50″ 22″x22″x55″ 25″x24″x57″ 25″x30″x60″
2 Pressed Bale Size (inch) 8″ x 8″ 12″ x 12″ 14″ x 14″ 16″ x 16″
3 Pressed Bale Weight (Kg) 15-25 25-35 35-45 45-60
4 Electric Motor (HP) 25 25 25 30
5 Pressing Scrap Time (second) 45-50 50-55 55-60 60-80
6 Production/Shift (tons) 8-10 10-12 12-14 14-16
7 Oil Tank Capacity (Ltr.) 700 700 800 1000

Please Note : waste paper baling machine Bale production depends on working Shift hours and Labourers work.



HYDRAULIC WASTE PAPER BALING MACHINE IN TRIPLE ACTION JUMBO,CAPACITY 200 TONS

waste paper baling press machine

With the assist of experts, we are engaged in offering to our customers a wide range of Hydraulic Waste Paper Baling Machine. Our presented product is developed by well-informed experts employing the best quality material which is obtained from trustworthy retailers of market. This product is extremely used in the market owing to their sturdy nature. In addition, this product is available at market leading costs.



S.NO. MODEL NO. SH-999  SH-1000
1.      Scrap Containing Box Size 30”x36”x73” 30”x40”x76”
2.      Pressed Bale Size 18”x18” 20”x20”
3.      Pressed Bale Weight (Kg) 50-60 in waste paper 60-80 in waste paper
4.      Electric Motor (HP) 50 60
5.      Pressing Scrap Time (second) 90- 100
6.      Production/Shift(tons) 10-12 12-15
7.      Oil Tank Capacity (Ltr) 1400 1600
8.      Warrantee 1 Year 1 Year
9.      Delivery Time          AVAILABLE AVAILABLE
10.    Machine length in foot 16-17 17-18
11.    Machine height in foot 7-7.5 7.5-8
12.    Machine width with side cylinder in foot 10-11 11-12
13.    Machine width without cylinder in foot 6.5-7 7-7.5
14.    Provided     Tamper Plate·         Heat Exchanger (Chiller)

·         Bale Remover

·         Double main cylinder

·         Hydraulic hoper

    Tamper Plate·         Heat Exchanger (Chiller)

·         Bale Remover

·         Double main cylinder

·         Hydraulic hoper

Bale production depends on PRESSING MATERIAL & Labourers work.


HYDRAULIC WASTE PAPER BALING MACHINE TRIPLE ACTION SUPER JUMBO MODEL,CAPACITY 300 TONS

hydraulic waste paper baling press machine

We have come up with superior quality Hydraulic waste Paper Baling Machines incorporated with big Body. These machines are used for bailing bundles of waste papers. Our experts are designing these machines as per industry quality standards. These machines feature durability, excellent performance and strength. We have made available these Hydraulic waste Paper Bailing Machines at unbelievable rates to our clients.



S.NO. MODEL NO. SH-1001 SH-1002
1.    Scrap Containing Box Size 36″x44″x84″ 50″x55″x105″
2.    Pressed Bale Size 24″x24″ 30″x30″
3.    Pressed Bale Weight (Kg) 100-150  in waste paper 150-200 in waste paper
4.    Electric Motor (HP) 60 120
5.    Production/hour 2-3 tons 4-5 tons
6.    Pressing Scrap Time (second) 100 120
7.    Oil Tank Capacity (Ltr) 2200 3000
8. Provided Tamper Plate,chiller,bale remover,shearing blade,,hydraulic hoper,Double main cylinder Tamper Plate,chiller,bale remover,shearing blade,hydraulic hoper, Double main cylinder
9.    Delivery Period 8-9 weeks 9-10 weeks
10.  Warrantee One Year One Year


No need of rope to tie

https://www.youtube.com/watch?v=q0IdxdULn3Q
