baling press machine for carton,baling press machine for rafiya,baling press machine for cardboard sheet 1ply to 10 ply,baling press machine for duplex

  • baling press machine for baling scrap generated from human resources etc,well this machine is capable of compacting scrap into compaction by decreasing its volume
  • A heavy machine meant for fast and efficient working for recycling scrap.available in three variant – (manual scrap baling press,semi automatic scrap baling press,fully automatic scrap baling press (pannel/plc)
  • Equipped with six cylinders and double main cylinder the machine is able to produce Bales in the range of 70Kg to 300 Kg.
  • Machine is available in different sizes meant for satisfying needs of all kind.
 Many retail and service businesses, such as packaging industries, scrap godown owner,scrap business man use baling press machine to reduce the volume of non-recyclable waste as well as curb nuisance such as rodents and smell. In the hospitality industry tolerance for such nuisances is particularly low. These compactors typically come in electric and hydraulic operation, with quite a few loading configurations.

VERTICAL BALING PRESS MACHINE(single action)

Need ROPE TO TIE A BALE,

3 manual ties

vertical Baling press machine

Pet Baling machine

Capacity of machine30 ton(sh-99)50 ton(sh-100)
Chamber size23”X23”X35”35”x35”x47”
Bale size(inch)23”X23”X23-28”35(L)X35(w)
Approx weight of bale50 to 80 kgs.100 to 130 kgs.
 OIL TANK 300 LTR 450 LTR
No. of cylinderOne nos.One nos.
Operatingmanual/automaticmanual/automatic
Production rates8 to 10 min. per bale10 to 12 min. per bale
Electric motor7.5 H.P./1500 RPM10 H.P./1500 RPM
 Warrantee 1 year 1 year

machine used for pressing business cards, aperture cards, postcards, playing cards,  and other uses which require higher durability than regular paper.



IN DOUBLE ACTION MODELNEED ROPE TO TIE A BALE FOR PAPER,CARDBOARD,CARTON,CORRUGATED BOXES,WASTE PAPER

baling press machineSILENT FEATURE-

can press any strength single thick sheet of paper to complex configurations featuring multiple corrugated and uncorrugated layers.

good for packaging company

easily pressed wax paper

Sl. No.SpecificationSh-001Sh-002Sh-003Sh-004
1Container Box Size (inch)20″x18″x56″22″x20″x56″22″x22″x57″24″x22″x57″
2Pressed Bale Size (inch)12″ x 18″12″ x 20″13″ x 22″13″ x 24″
3Pressed BaleWeight (Kg)approx.15-25(in ms scrap)10-18(in carton)10-20(in aluminium)

10-20(pet bottle)

20-40(in ms scrap)15-25(in carton)15-25(in aluminium)

15-25(pet bottle)

35-60(in ms scrap)20-35(in carton)20-25(in aluminium)

20-35(pet bottle)

45-70(in ms scrap)30-50(in carton)20-35(in aluminium)

30-50(pet bottle)

4Electric Motor (HP)20202525
5Pressing Scrap Time (second)35-4040-4545-5050-55
6Production/Shift (tons)6-88-1010-1212-14
7Oil Tank Capacity (Ltr.)700700700700


triple is good for pressing hard and strength paper like-

baler press machine

  • Containerboard, used in the production of corrugated fiberboard.
  • Folding boxboard, made up of multiple layers of chemical and mechanical pulp.
  • Solid bleached board is made purely from bleached chemical pulp and usually has a mineral or synthetic pigment.
  • Solid unbleached board is typically made of unbleached chemical pulp.
  • White lined chipboard is typically made from layers
  • Binder’s board, a paperboard used in bookbinding for making hardcovers.
IN TRIPLE ACTION MODEL – NO NEED ROPE TO TIE A BALE catalog covers, binder’s board for bookbinding, scrapbooking,

Sl. No.SpecificationSh-783Sh-784Sh-785Sh-786
1Container Box Size (inch)20″x20″x50″22″x22″x55″25″x24″x57″25″x30″x60″
2Pressed Bale Size (inch)8″ x 8″12″ x 12″14″ x 14″16″ x 16″
3Pressed Bale Weight (Kg)approx.20-25(in ms scrap)10-20(in carton)10-20(in aluminium)

10-20(pet bottle)

25-35(in ms scrap)15-25(in carton)15-25(in aluminium)

15-25(pet bottle)

35-50(in ms scrap)25-35(in carton)15-30(in aluminium)

20-40(pet bottle)

45-70(in ms scrap)30-50(in carton)

20-35(in aluminium)

30-50(pet bottle)



4Electric Motor (HP)25253030
5Pressing Scrap Time (second)45-5050-5555-6060-80
6Production/Shift (tons)8-1010-1212-1414-16
7Oil Tank Capacity (Ltr.)7007008001000
